Additional information
| Suitable Excavator | 1,8÷3 Ton | 3968÷6614 Lbs |
|---|---|
| Operating Weight | 173 kg | 381,4 lbs |
| Tool Diameter | 49 mm | 1,93 in |
| Oil Supply | 30÷45 l/min | 8÷12 GPM |
| Breaker Working Pressure | 100÷150 bar | 1450÷2176 PSI |
| Relief Pressure Setting | 180 bar | 2611 PSI |
| Max Back Pressure | 25 bar | 363 PSI |
| Input Power (Max) | 9 kW | 12,6 HP |
| Impact Energy Class | 540 J | 399 Ft/lbs |
| Impact Rate | 650÷1000 BPM | 650÷1000 BPM |
| Max Temperature Hydraulic Oil | 80 °C | 176 °F |
| Recommended Inlet Line Size (Ø Min.) | 12 mm | 0,47 in |
| Recommended Return Line Size (Ø Min.) | 14 mm | 0,55 in |
| Suggested Min Flex Hoses Length | 1400 mm | 55,1 in |
| Hose Connection at the Breaker's Inlet Line | 1/2" G | 1/2" G |
| Hose Connection at the Breaker's Return Line | 1/2″ G | 1/2″ G |
